The OVALEX is a fully automatic soap press designed to stamp toilet soap bars in bandless, banded, and specialty shapes. It is pneumatically operated and an ideal solution for small to medium production requirements.

​

The press is supplied complete with:

• An intermittent motion slug-infeed conveyor driven by a 0.18 kW variable-speed motor.

• A pneumatic gripper system for transferring incoming slugs between the stamping dies.

• A vertical stamping unit with a pneumatic piston operating through a toggle-joint mechanical leverage system. This system elegantly multiplies the stamping pressure precisely when the top die approaches the bottom die, ensuring high stamping pressure and rapid operation with a single-stroke stamping action.

• A die set that can accommodate one, two, or three cavities, depending on the size of the stamped bar. A single-cavity die produces one bar per cycle, a double-cavity die produces two, and a triple-cavity die produces three bars per stamping cycle.

• Adjustable stamped bar weight, controlled mechanically by adjusting the clearance between the upper and lower dies. This feature also prevents potential die damage.

• Linear bearings that ensure precise die movement.

• A bottom die that moves forward after stamping to facilitate bar removal via a suction-cup discharge system.

• Suction-cup discharge system that lowers, removes the stamped bars, passes them through the deflashing plate, and releases them onto the discharge conveyor.

• A discharge conveyor driven by a 0.18 kW variable-speed motor.

• An electrical control panel equipped with a Programmable Logic Controller (PLC) and a cam programmer for full control and monitoring of the press functions, product position sensors, frequency inverters, safety switches, and all necessary components.

• A filter/regulator/lubricator unit and a compressed air tank.

• Aluminum and transparent PVC safety guards.

• An integrated die set cooling system.

• Compliance with CE regulations.
